Abrites MN032 + MN034 for Mercedes Benz Bundle

Product Description:

Software Activation From Abrites with Product Number: MKON423

Included Products

• Abrites MN032 DAS Manager for Mercedes BenzFBS3/FBS4 cars
• Abrites - MN034 - FBS4 Personalization Expert License Activation

Abrites - MN034 - FBS4 Personalization Expert License Activation

Abrites MN034 - FBS4 Personalization Expert allows personalization of modules from the FBS4 generation of Mercedes DAS (Drive Authorization System). The FBS4 Personalization Expert allows the replacement of electronic components with or without the existence of previously saved personalization data. It is the only tool for the moment which allows the making of FBS4/ DAS4 modules virgin and readapting them from one vehicle to another i.e. reusability of electronic control modules from the DAS system in Mercedes vehicles.

With the MN034 you can:

• Read personalization data via OBD and on bench
• Make modules virgin and personalizing them by OBD and on bench
• Reuse more affordable second-hand modules from one car to another
• Access personalization data from Mercedes Hybrid modules such as battery controllers
• 48V system controllers such as starter generators
• Get personalization data from VGS4 NAG2 transmission controller and adapt from one vehicle to another
• Personalize 8G-DCT transmission controller, make virgin and adapt from one vehicle to another
• Personalize Engine control units, make virgin and adapt from one vehicle to another
• Personalize all types of virgin ECUs with previously available personalization data unsupported for bench programming (EMS74, MRD1, MRG1 – year 2021+)
• Personalize MED177, MED40, CR60LS ECUs when NO PREVIOUSLY PERSONALIZATION DATA IS AVAILABLE!

All owners of the MN032 license (acquired before December 13, 2023) can access the MN034 free of charge. AVDI and AMS are required.

Abrites MN032 DAS Manager for Mercedes BenzFBS3/FBS4 cars

MN032 is a world leader in terms of Mercedes-Benz vehicles module replacement, key and remote programming, both for new and used control units.

FBS4 functionalities

• Reset of FBS4 Engine control units to virgin state
• Read the personalization data from a FBS4 ECU and saving it to a file for future use
• Program personalization data from a previously saved file to a FBS4 ECU
• FBS4 ECU Activation

Currently supported ECUs (produced until MY2020):

• CR40 (EDC17C43)
• CR41 (EDC17C66)
• CR42 (EDC17CP46)
• CR43 (EDC17CP60)
• CR6 (EDC17CP10)
• CR60 (EDC17CP46)
• CR61 (EDC17CP57)
• MED40 (MED17.7.1 and MED17.7.2)
• MED177 (MED17.7.3, MED17.7.5, MED17.7.8)
• CRD3
• CRD3H
• CRD3S2

VGS-NAG2 FBS4 Transmission control units are also supported for renewal.

The newly added modules include:

• ECU CRR1 (SID307) and CRR1+(SID310) – Done completely by OBD.
• ECU MRD1, MRG1 (manufactured up to 2021) – Bench connection using ZN051 Distribution box and EP003 are required.
• ECU CRR2 (MD1CS006) – Bench connection using ZN051 Distribution box and EP003 are required.
• ECU MED41 (MED17.7.7) – Bench connection using ZN051 Distribution box and EP003 are required.
• Transmission Control Unit VGSNAG3 (9-Gear) - Bench connection using ZN051 Distribution box and EP003 are required.
• Transmission Control Unit VGS2-FDCT (Dual Clutch Transmission)- Bench connection using ZN051 Distribution box and EP003 are required.
• Direct Shift Module (DSM) – ABPROG (ZN030) is required to connect to the module’s microcontroller and read data directly from it to extract the data and use it with the Abrites software.


FBS3 functionalities

Module replacement:

• Service password reading
• Read/Save/Update FBS Data
• Transfer FBS Data to a replacement unit
• Make each DAS/FBS module virgin, personalise and activate it
• Read/Save/Update Coding (the only way to avoid online SCN coding)
• Transfer Coding to a replacement unit

Key programming:

• Easily extract the EZS/EIS key password
• Program all types of DAS2 keys
• Program Infra Red keys to DAS3 (FBS3)
• Enable and disable key positions

Supported Models:

• W202/W208/W210
• W203/W209/W211/W219
• W169/W245
• W220/W215/R230
• W204/W207/W212/W218
• W221/W216/W251/W164/X164
• W176/W246/W242/W117
• W166/X166

Supported Modules are all DAS related modules

• ECUs
• TCUs (7G-Tronic)
• ISM
• DSM
• ESL/EZS
• EIS/ELV

Other features:

• Program the Abrites Emulators for Mercedes vehicles (EM001, EM004, EM005, EM008, EM009, EM012, EM014)
• Reset the mileage of any supported EZS/EIS.

Additional and required tools:

• ZN051 Abrites Distribution Box
• ZN002 Abrites PROTAG programmer
• ZN030 Abrites ABPROG
• Abrites IR keys, keys with replica shells and Abrites IR PCBs: TA13, TA14, TA15, TA21, TA22, TA52

  The ZN076 is highly reccomended for faster reading information from the EZS/EIS of Mercedes-Benz vehicles with IR locks.
