Abrites MN032 DAS Manager for Mercedes BenzFBS3/FBS4 cars MK18002
Abrites MN032 DAS Manager for Mercedes BenzFBS3/FBS4 cars
Abrites MN032 DAS Manager for Mercedes BenzFBS3/FBS4 cars

Abrites MN032 DAS Manager for Mercedes BenzFBS3/FBS4 cars

Write Review
$2,795.69 (€2,600.00)
Add to Wishlist
Product Code: MK18002
Categories Software Activation
Manufacturer Abrites
In StockIn Stock Digital ProductDigital Product
Product Specifications
Manufacturer ABRITES

Abrites MN027 - Mercedes-Benz FBS4 Manager

Product Description:

Abrites MN032 is a world leader in terms of Mercedes-Benz vehicles module replacement, key and remote programming, both for new

Software Activation From Abrites with Product Number: MK8002

Specs:

Manufacturer: ABRITES

MN032 is a world leader in terms of Mercedes-Benz vehicles module replacement, key and remote programming, both for new and used control units.

FBS4 functionalities

  • Reset of FBS4 Engine control units to virgin state
  • Read the personalization data from a FBS4 ECU and saving it to a file for future use
  • Program personalization data from a previously saved file to a FBS4 ECU
  • FBS4 ECU Activation

Currently supported ECUs (produced until MY2020):

  • CR40 (EDC17C43)
  • CR41 (EDC17C66)
  • CR42 (EDC17CP46)
  • CR43 (EDC17CP60)
  • CR6 (EDC17CP10)
  • CR60 (EDC17CP46)
  • CR61 (EDC17CP57)
  • MED40 (MED17.7.1 and MED17.7.2)
  • MED177 (MED17.7.3, MED17.7.5, MED17.7.8)
  • CRD3
  • CRD3H
  • CRD3S2

VGS-NAG2 FBS4 Transmission control units are also supported for renewal.

The newly added modules include:

• ECU CRR1 (SID307) and CRR1+(SID310) – Done completely by OBD.
• ECU MRD1, MRG1 (manufactured up to 2021) – Bench connection using ZN051 Distribution box and EP003 are required.
• ECU CRR2 (MD1CS006) – Bench connection using ZN051 Distribution box and EP003 are required.
• ECU MED41 (MED17.7.7) – Bench connection using ZN051 Distribution box and EP003 are required.
• Transmission Control Unit VGSNAG3 (9-Gear) - Bench connection using ZN051 Distribution box and EP003 are required.
• Transmission Control Unit VGS2-FDCT (Dual Clutch Transmission)- Bench connection using ZN051 Distribution box and EP003 are required.
• Direct Shift Module (DSM) – ABPROG (ZN030) is required to connect to the module’s microcontroller and read data directly from it to extract the data and use it with the Abrites software.


FBS3 functionalities

Module replacement:

  • Service password reading
  • Read/Save/Update FBS Data
  • Transfer FBS Data to a replacement unit
  • Make each DAS/FBS module virgin, personalise and activate it
  • Read/Save/Update Coding (the only way to avoid online SCN coding)
  • Transfer Coding to a replacement unit


Key programming:

  • Easily extract the EZS/EIS key password
  • Program all types of DAS2 keys
  • Program Infra Red keys to DAS3 (FBS3)
  • Enable and disable key positions



Supported Models:

  • W202/W208/W210
  • W203/W209/W211/W219
  • W169/W245
  • W220/W215/R230
  • W204/W207/W212/W218
  • W221/W216/W251/W164/X164
  • W176/W246/W242/W117
  • W166/X166


Supported Modules are all DAS related modules

  • ECUs
  • TCUs (7G-Tronic)
  • ISM
  • DSM
  • ESL/EZS
  • EIS/ELV


Other features:

  • Program the Abrites Emulators for Mercedes vehicles (EM001, EM004, EM005, EM008, EM009, EM012, EM014)
  • Reset the mileage of any supported EZS/EIS.



Additional and required tools:

  • ZN051 Abrites Distribution Box
  • ZN002 Abrites PROTAG programmer
  • ZN030 Abrites ABPROG
  • Abrites IR keys, keys with replica shells and Abrites IR PCBs: TA13, TA14, TA15, TA21, TA22, TA52

    The ZN076 is highly reccomended for faster reading information from the EZS/EIS of Mercedes-Benz vehicles with IR locks.


N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function.
